Cerere de  oferta

Procurare si livrare echipament

Asociația Obștească „Media Alternativă” este o organizație non-guvernamentală, apolitică și non-profit, înregistrată la Ministerul Justiției la 13 martie 2017  cu nr. MD 476473, deținătoarea licenței de emisie a postului TV8.

In cadrul proiectului ’’Bilingual aproach to news and entertaiment’’ cu nr. SMD70024GR0515 finanțat de către Ambasada Statelor Unite în Moldova inperioada 31.07.2024-30.07.2026

 A.O. „Media Alternativă” solicită o ofertă pentru procurare și livrare a echipamentului, și anume :

Camera System - Technical Specifications

CAMERA-IMAGING

Image Sensor

• Type: 2/3"-Type CMOS
• Sensor Resolution: Effective: 8.3 Megapixel (3840 x 2160)
• Horizontal Resolution: 2000 TV Lines or More
• Gain: -6 to 12 dB
• Sensitivity: f/11 at 2000 lux 89.9% Reflectance (at 3200K, 50 Hz)
• Signal-to-Noise Ratio: -62 dB

Lens

• Focal Length:2 to 164mm
• Optical Zoom Ratio: 20x
• Maximum Aperture: f/1.9
• Minimum Aperture: f/16
• Minimum Focus Distance:4" / 90.0 cm; Macro: 0.4" / 1.0 cm
• Filter Size: 82 mm
• Control Rings: Focus, Zoom, Iris
• Focus Control: Autofocus, Manual Focus

CAMERA BODY

General

• Lens Mount: B4 Mount
• Shutter Type: Electronic Rolling Shutter
• Shutter Speed: 1/2000 to 1/100 Second
• Built-In ND Filter: Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters
• Broadcast System Compatibility: NTSC, PAL

Interfaces

• CCU I/O: 1x Neutrik
• Video I/O: 1x BNC (12G-SDI) Input/Output, 1x BNC (HD-SDI) Output
• Audio I/O: 2x XLR 3-Pin Mic/Line Input, 1x 1/8" / 3.5 mm TRRS Headphone/Mic Output, 1x XLR 5-Pin Intercom Input/Output
• Lens Control: 1x 12-Pin
• Other I/O: 1x 20-Pin Viewfinder Output, 1x BNC (Genlock) Control, 1x Hirose 8-Pin (RS-422) Control

RECORDING

External Recording Modes

SDI/BNC / Optical Fiber

• HD (1920 x 1080p) at 50/59.94/60.00 fps
• HD (1920 x 1080i) at 50/59.94 fps
• HD (1920 x 1080PsF) at 23.98/24.00/25/29.97 fps

Video Features

• Variable Frame Rates: Up to 60 fps
• Gamma Curve: HDR-HLG, Rec2020, Sony S-Log 3

ELECTRONIC VIEWFINDER (EVF)

• Display Type: OLED
• Size:4"
• Resolution: 960 x 540

CAMERA CONTROL UNIT (CCU)

Input/Output

• Fiber Cable Supported: Single Mode LC, CCFN
• Camera Connector: 1x Neutrik Optical Fiber
• Power Supply Maximum Distance: 300 m
• Maximum Distance: 10 km
• Intercom: Front Panel: 4-Pole Mini Jack, Intercom/Program/Tally (Red, Green) / Preview, Out: DB-25
• Remote: 1x 8-Pin
• Trunk: 1x 12-Pin, Trunk: 1x RJ45
• LAN: 1x RJ45

Reference Input

• Connectors: 2x BNC
• HD Input: SMPTE 274M, Tri-Level Sync: 0.6 Vp-p, 75 Ohms
• SD Input: Black Burst, NTSC: 0.286 Vp-p, 75 Ohms, PAL: 0.3 Vp-p, 75 Ohms

Prompter

• Connectors: 2x BNC
• Input: VBS, 1.0 Vp-p, 75 Ohms, 1x System
• Output: Loop-Through

Power

• AC Input: 100-240 VAC

Video Output

3G/HD/SD-SDI: 4x BNC

• 3G-SDI: SMPTE ST292, 0.8 Vp-p, 75 Ohms, Bit Rate: 1.485 Gb/s / 1.4835 Gb/s
• HD-SDI: SMPTE ST292, 0.8 Vp-p, 75 Ohms, 1.485 Gb/s / 1.4835 Gb/s
• SD-SDI: SMPTE ST259, 0.8 Vp-p, 75 Ohms, Bit Rate: 270 Mb/s

12G/6G/3G/HD-SDI: 2x BNC

• 12G-SDI: SMPTE ST2082, 0.8 Vp-p, 75 Ohms, Bit Rate: 11.88 Gb/s / 11.868 Gb/s
• 6G-SDI: SMPTE ST2081, 0.8 Vp-p, 75 Ohms, Bit Rate: 5.940 Gb/s / 5.934 Gb/s
• 3G SDI: SMPTE ST424/425 Level-A/B, 0.8 Vp-p, 75 Ohms
• HD SDI: SMPTE ST292, 0.8 Vp-p, 75 Ohms, Bit Rate: 1.485 Gb/s / 1.4835 Gb/s

Character Display

• Connector: 1x BNC: VBS, 1 Vp-p, 75 Ohms
• HD Sync: Tri-level Sync, 0.6 Vp-p, 75 Ohms
• SD Sync: NTSC: 0.286 Vp-p, 75 Ohms, PAL: 0.3 Vp-p, 75 Ohms

Audio Output

• Channels: Channel-1, Channel-2
• Connectors: 2x 3-Pin XLR
• Level: 0/-20 dBu / +4 dBu

ADDITIONAL COMPONENTS

Full-Servo Kit

Compatible with camera lens including Digital Focus Servo, Digital Zoom Servo and other accessories

Optical Fiber Cable

• Type: Hybrid Type
• Minimum Length: 150m

Warranty: 3 years

MULTI CAMERA REMOTE CONTROL PANEL (RCP)

Master Setup Unit

Multi camera remote control panel for system cameras (horizontal type) - compatible with camera position 1

Key Features

Flexible, Scalable System Configuration

• The multi camera remote control panel can be configured for use with large and small-scale camera control systems
• Can flexibly control up to 96 units of system camera

Customizable Switches

• Functions and Menu can be mapped to the assignable keys via the Menu Control page, allowing quick and easy access
• Maximum of 21 keys available: F1 to F11 and 1 to 10 on the panel
• Available via SW Customize menu with categorized items

LCD Touchpanel

• Large 7-inch WVGA (800x480) panel with improved visibility

High Speed LAN Connection

• Supports connectivity via 1000Base-T Ethernet LAN
• Single connection by CCA 8-pin cable

Status Indication

• Status key displays connected camera/CCU/BPU's alert status on LCD panel
• Some setting status can also be indicated

Warranty: 3 years

PEDESTAL REQUIREMENTS

Technical Specifications

• Load Capacity: Minimum 40 kg to support camera head with lens and accessories
• Height Range: Adjustable from 75 cm to 150 cm (minimum recommended)
• Column Type: Pneumatic or hydraulic counterbalance system
• Wheel Configuration: 3-wheel dolly base with individual wheel locks
• Wheel Diameter: Minimum 10 cm for smooth studio floor operation
• Steering: Cable or center column steering system
• Cable Guards: Integrated cable management system
• Leveling: Fine adjustment leveling system
• Base Diameter: Minimum 75 cm for stability

Performance Requirements

• Smooth counterbalance operation throughout height range
• Precise height adjustment with position lock
• Stable operation during camera movement
• Compatible with standard studio flooring
• Easy transport and setup capability

Mounting Interface

• Standard: 100mm or 150mm bowl mount
• Compatibility: Must support camera head weight and balance requirements

Warranty: Minimum 2 years

Datele si specificațiile tehnice, pot fi solicitate la adresa electronică: tudor.bologan@tv8.md, achizitii@tv8.md. Oferta trebuie să indice prețurile în MDL.

Criteriile de evaluare:

Ofertele vor fi evaluate în funcție de raportul preț-calitate și promptitudinea livrării bunului. Ofertele recepționate vor fi deschise și evaluate de un comitet intern de evaluare în data de 29 Octombrie 2025. Doar compania selectată va fi contactată!

Data limită de depunere a ofertelor: 28 Octombrie 2025

Ofertele vor fi expediate la adresa de email:  achizitii@tv8.md

Data limită de livrare a echipamentului – 30 zile din data semnarii contractului.
